Mill Crusher KL-701-1E Hand Push Pulverizer Cutter Speed 3000rpm
Main technical parameters |
| Model | KL-701-1E diesel (electric start) | KL-701 gasoline (hand start) | KL-703 gasoline (hand start) | KL-703-1E diesel (electric start) | KL-702 (power optional) | KL-704C gasoline (hand start) |
| Branch diameter(mm) | 3-100 | 3-100 | 3-150 | 3-150 | 3-120 | 3-60 |
| Paring knife(mm) | 5.5*300 | 5.5*300 | 5.5*300 | 5.5*300 | 7.5*56*300 | 5.5*300 |
| Cutter speed(rpm) | 3000 | 2700 | 3600 | 3000 | 2600 | 2800 |
| Outlet | Upper discharge | Upper discharge | Upper discharge | Upper discharge | Upper discharge + bottom discharge | Upper discharge |
| Engine model | 188F diesel engine | Single-cylinder four-stroke air-cooled engine192F | Single-cylinder four-stroke air-cooled engine192F | 188F diesel engine | 192F Gasoline and diesel/7.5kw motor | Single-cylinder four-stroke air-cooled engine170F |
| Engine capacity(cc) | 389 | 420 | 420 | 430cc/7.5kw | 420cc/7.5kw | 208 |
| Output Power(HP) | 13 | 18 | 18 | 13 | 18 | 7.5 |
| Diesel capacity(L) | 5.5 | 6.5 | 6.5 | 6.5 | 6.5 | 3.6 |
| Oil capacity(L) | 1.5 | 1.1 | 1.1 | 1.1 | 1.1 | 0.6 |
| Start method | Electric start | Hand pull recoil start | Hand pull recoil start | Electronic ignition | Electronic ignition | Hand pull recoil start |
| Fuel type | 0#diesel fuel | 92#Unleaded gasoline | 92#Unleaded gasoline | 0#diesel fuel | 0#diesel fuel /92#gasoline | 92#gasoline |
| G.W/N.W(kgs) | 200/180 | 180/160 | 200/190 | 200/190 | 240/220 | 130/120 |
| Package Size(cm) | 122*58*96 | 122*58*96 | 155*80*125 | 155*80*125 | 122*58*96 | 113*41*82 |
Scope of application |
- Widely used in various occasions, strong adaptability.
- Mainly used for cattle and sheep feed, edible fungus base material,
also used as fertilizer, mechanism charcoal, Buddhist incense
factory, timber factory, mushroom cultivation.
|
Features |
- Hand-push movement, adapt to various terrains
- Reasonable structure, simple operation, stable output
- Airflow impact, strong power, complete crushing
- Real materials, stable and durable, beautiful appearance
|
Crushing principle: By combining a rapidly rotating blade with a
sharp blade, various branches and plants can be crushed (branches,
leaves, straw, etc.). Compared to incineration treatment, crushing
treatment is more environmentally friendly, and waste can also be
reused and crushed as fertilizer, returned to the field, culture
medium, etc
The shredder is suitable for shredding residual branches, branches,
and leaves in orchards, forest factories, tea factories, nurseries,
gardens, and other fields. Due to its convenient use, it is
suitable for shredding residual branches, leaves, and bark in
parks, campuses, corporate units, and urban communities. It can be
used as a mushroom base material, safe, reliable, practical, with
high crushing efficiency and good effect. It is an agricultural
equipment.
